PFL Vertical Compound Sand Making Machine

Compound sand maker, also known as compound sand crusher, belongs to fine crushing equipment, which is widely used in construction materials, construction sand making, chemical industry, metallurgy, electric power energy and other process. It is mainly used for crushing materials below medium hardness, and not only has strong processing capacity in crushing soft rock, but also has good granularity of finished products. Compared with the vertical impact crusher, the cost is relatively low, which is an optimal choice for medium and small investors.

Leave Message

Gallery send e-mail sales05@cinacharm.com

Product show

Leave Message Online

Performance Parameter

Model	Feeding size(mm)	Discharging size(mm)	Main axis rotation(r/min)	Capacity (t/h)	Power (kW)	Overall dimension(L×W×H)(mm)
PFL-750lll	<100	<3	800~1350	8~20	45	2370×1150×1300
PFL-1000lll	<120	<3	650~980	15~30	55	2600×1420×1520
PFL-1250lll	<150	<3	510~770	35~45	90	3070×1690×1660
PFL-1500lll	<180	<3	430~640	50~70	132	3390×2050×2030
PFL-1750lll	<200	<3	420~540	70~100	160	3820×2360×2080
PFL-2000lll	<220	<3	360~500	90~20	200	4080×2610×2180
PFL-2300lll	<240	<3	330~450	120~160	250	4472×2930×2554

Any change of the technical data shall not be advised additionally.

Maintenance tips

The equipment should be lubricated according to requirements, and you should pay attention to the oil temperature, oil pressure, flow rate and other parameters.

When excessive noise or vibration occurs during the operation, the equipment should be shut down and inspected quickly.

Pay attention to the product quality and productivity, in order to solve the problem as soon as we find it.
