PF Series Impact Crusher

PF series impact crusher is a kind of impact breaker developed by our company combining with advanced technology and domestic sand & gravel industry. With special structural design and advanced manufacturing technology, it is widely used in crushing various soft, medium and hard ores, and is able to carry out coarse, medium, and fine crushing in primary and secondary crushing. It is mainly used in industries such as mining, construction, chemical, cement, metallurgy and other industries. It is widely used in all kinds of ore crushing, railway, highway and construction industries production of artificial sand and gravel.

Leave Message


Gallery send e-mail sales05@cinacharm.com

PF Series Impact Crusher

Home > Products > Crushing Equipment >

PF Series Impact Crusher

PF series impact crusher is a kind of impact breaker developed by our company combining with advanced technology and domestic sand & gravel industry. With special structural design and advanced manufacturing technology, it is widely used in crushing various soft, medium and hard ores, and is able to carry out coarse, medium, and fine crushing in primary and secondary crushing. It is mainly used in industries such as mining, construction, chemical, cement, metallurgy and other industries. It is widely used in all kinds of ore crushing, railway, highway and construction industries production of artificial sand and gravel.

Leave Message


Gallery send e-mail sales05@cinacharm.com

Product show

Leave Message Online

Technical Parameter

Model Rotor diameter (mm) Feeding opening size (mm) Max. Feeding side length (mm) Capacity (t/h) Motor Power (kW) Overall Dimension(L×W×H) (mm)
PF-1820 Φ1800×2000 1620×2040 800 550-800 630-710 4471×3250×4008
PF-1620 Φ1612×2000 1315×2040 700 400-600 500 4236×3572×3735
PF-1520 Φ1512×2000 1315×2040 700 350-450 400-450 4138×3422×3649
PF-1320 Φ1320×2000 900×2030 500 160-350 260-300 3320×3218×2613
PF-1318 Φ1320×1500 880×2000 350 150-260 220-260 3100×3210×2613
PF-1315 Φ1320×1500 860×1520 350 120-250 180-220 3100×2800×3160
PF-1214 Φ1250×1400 400×1430 300 90-180 132-160 2850×2400×2900
PF-1210 Φ1250×1050 400×1080 300 70-130 110-132 2800×2150×2900
PF-1010 Φ1035×1050 400×1080 300 50-90 55-75 2650×2150×2900
PF-1007 Φ1000×700 400×730 250 15-60 37-55 2440×1580×2672

Any change of the technical data shall not be advised additionally.
